HiLetgo 2pcs GP2Y0E03 Infrared Distance Measurement Sensor Module 4-50CM Range I2C Analog Output 2.7V-5V for Cleaning Robot...

1 REVIEW

SKU: L1403841

VENDOR: HiLetgo

$24.86$21.29

You Save: $3.57 (15%)

Hurry! Only 10 Left in Stock!

HiLetgo 2pcs GP2Y0E03 Infrared Distance Measurement Sensor Module 4-50CM Range I2C Analog Output 2.7V-5V for Cleaning Robot
GP2Y0E03 Infrared Distance Measurement Sensor Module
CMOS integrated combination, digital I2C Analog Output
Infrared LED and CMOS image sensor, built-in signal processing circuit
Working voltage: 2.7V-5V





  • FREE standard shipping within the United States(3-6 Days)on all orders!
  • 100% money back guarantee for items not delivered or damaged during shipping.
  • Safe and secure checkout with our high quality encryption
  • Shipping services: UPS, FedEx, USPS.
  • Only ship to the lower 48 states, no APO/FPO addresses or PO Boxes allowed.
  • Local pickups and combined shipping options are not provided at this time.


  • You can return a product for up to 30 days from the date you purchased it.
  • Any product you return must be in the same condition you received it and in the original packaging. Please keep the receipt.
  • A full refund if you don’t receive your order
  • A full refund if your order does not arrive within the guaranteed time (6-7 business days not including 1 processing day.)

We accept payment by any of the following methods:
Credit Cards, PayPal, Shop Pay, Apple Pay, Google Pay, Amazon Pay, Meta Pay

Customer satisfaction is very important to us.
If you have any problem with your order, please contact us and we will do our best to make you satisfied.



If you have any queries, please contact us via

Support@ZeeBooth.com

We usually respond within 24 hours on weekdays.


Customer Reviews

Based on 1 review
0%
(0)
100%
(1)
0%
(0)
0%
(0)
0%
(0)
A
Amazon Customer
Tricky chip to use, no great libraries out there for arduino

Not an east chip to use. The listing says its 5v and 3.3 volts, but the datasheet shows only VDD can be either and the rest needs 3.3v. A few things I learned along the way: 1) The i2c interface seems to be more accurate than analog. 3% variance instead of 9% between devices. 2) For arduino code look up GP2Y0E02B instead. I tried some examples online but had issues reading the SHIFT register until I added Wire.requestFrom(addr, 1) before checking Wire.available() 3) If you are just using analog I would connect VIN and GPIO1 to 3.3v. When floating I was getting inconsistent readings. 4) There is code on github to change the i2c address. It involves touching an extra pin to one of the pads on the backside of the chip. And I had to change the forever sleep loop in that code to avoid the hardward watchdog on a NodeMCU. 5) The main datasheet doesnt give i2c details, for that look up: "GP2Y0E02A,GP2Y0E02B,GP2Y0E03 Application Note" Once all the kinks were worked out it seems pretty good. I get excellent results pointed at cardboard, but other materials read different.
