DC Miniture Circuit Breaker 2 Pole 25 Amp. 600V for Solar PV. MCB for Overload and Short Circuit Protection. Din Rail Mounted.
DC Miniture Circuit Breaker for Solar Installations
Rated Working Voltage Ue : 600Vdc Frame Current : 63A Rated Insulation Voltage Ui : 1000V Rated Impulse Withstand Voltage Uimp : 6Kv
Electrical Life : 2000 Cycles Mechanical Life: 20000 Cycles Overvoltage Category : III Pollution Degree : 3
Ingress Protection: IP40; Wiring port IP20 Resistance to humidity and heat: Class 2 Relative Humidity: ? 95 % Vibration : acc. to IEC60068-2-6 Shocks: acc. to IEC60068-2-27 Terminal capacity: 2.5-25mm² Fastening Torque of Terminals: 2.5 N
Ambient Temperature: -30°C~70°C Storage Temperature: -40°C~85°C Installation Method: DIN Elevation: ?2000m
2 x 4 x 5 inches; 0.63 ounces
