DSD TECH SH-B23A Bluetooth 2.0 to RS232 Serial Adapter with DB9 Converter...

Purchased as a inexpensive option to connect with my Microsquirt ecu. After downloading the app from the manufacture and following the instructions from Pfloor on the msextra forum, it connected immediately after pairing to my phone. I will ad the jumper wire to eliminate the need for external power (as shown by other reviewers). I am happy with the product.

No major issues. I got it for wireless serial with my Megasquirt MS3PNP. Added a jumper as shown to get voltage from the Ring Indicator pin to the chip. Works a treat without needing the power brick anymore.

I'm an IT hobbyist, not an IT professional. I have above average knowledge for sure. I'm using these for perhaps a unique use case, having one computer transmit data to another computer (multiple, actually). I'm a court reporter, and I can send my realtime transcription to other computers so it can be viewed by attorneys or whomever. There are a few ways to do this (many cloud based options charge high fees), but the classic/free way is via wired serial connection. Ancient tech, but (with a USB to serial cable) it works. I wondered, could I possibly find some wireless solution? And I found this. Like many others, hours of trial and error later, and it works! I could not get it to communicate with the built-in Bluetooth on my laptops, but when pairing it with the Startech USBBT1EDR2 (which I literally had lying around), it works like a charm. I wish I didn't need the extra Bluetooth dongle -- maybe a geekier man than me wouldn't -- but I'm happy.

Bought this to allow reading of RS232 scale to be placed inside a vac chamber, to allow wireless weights while chamber was sealed. Barely worked outside (have to move jumpers from PC-COM to DEVICE or scale would not respond at all), with power provided by computer USB port. Once placed inside chamber, power coming from a 5V supply (battery phone recharger) or from lithium battery stack, would turn off after 60s. Gave up. Odd that it worked with a computer 5V USB out, but not with 6.4V battery or phone recharger. Don't trust this to work - many other reviews about random product substitution. Other reviews have some workarounds that are handy, but look for a different widget than this.

The box is really nice. The entire thing must be taken apart when attempting to change the jumpers. Will not drive a DCE if the DCE required DTR/RTS/CTS hardware handshake (unlike usb portio interfaces). Also, be prepared with a null-modem to get 2/3 to cross and get a breakout box to debug. Do not see the +-10vdc level converter, so your device must respond to ttl levels. When programming a modem ignore all dtr and cts/rts settings. Here is a setup that might work: USRobotics Courier V.Everything Settings... B0 C1 E1 F1 M1 Q0 V1 X1 BAUD=9600 PARITY=N WORDLEN=8 DIAL=TONE ON HOOK TIMER &A1 &B0 &C0 &D0 &G0 &H0 &I4 &K1 &L0 &M4 &N0 &P0 &R1 &S0 &T5 &U0 &X0 &Y1 %N6 #CID=0 S00=000 S01=000 S02=043 S03=013 S04=010 S05=008 S06=002 S07=060 S08=002 S09=006 S10=014 S11=070 S12=050 S13=000 S14=001 S15=000 S16=000 S17=000 S18=000 S19=000 S20=000 S21=010 S22=017 S23=019 S24=150 S25=005 S26=001 S27=000 S28=008 S29=020 S30=000 S31=000 S32=009 S33=000 S34=000 S35=000 S36=000 S37=000 S38=000 S39=000 S40=000 S41=000 S42=126 S43=200 S44=015 S45=000 S46=000 S47=000 S48=000 S49=000 S50=000 S51=000 S52=000 S53=000 S54=064 S55=000 S56=000 S57=000 S58=000 S59=000 S60=000 S61=000 S62=000 S63=000 S64=000 S65=000 S66=000 S67=000 S68=000 S69=000 S70=000 I use: ati4 to print this out on an external USR modem. DSD tech support can't really help, they can just offer to do a replacement, which very nice, but not helpful. This is just got design issues, no hardware handshake, incorrect level voltages, etc. Replacement will not help! This is not an RS232 EIA compatible device...close, but not quite!
